LCVB-TYPE
Floor Plan
Technical Specification
| Reference | LCVB 25 | LCVB 40 |
|---|---|---|
| Flange Size | NW 25 | NW 40 |
| Conductance ( l/s) | 13 | 42 |
| Leak Rate (Pa·l/s) | Max. 2 X 10-10 | |
| Differential Pressure on Valve Seat | 1.3 | |
| A:Body B:Sealing Material | A : SUS 304 B : VITON | |
| Life Cycle | 50,000( Room Temperature ) | |
| Max. Baking Temperature(℃) | 120,70( Operating Part ) | |
| Weight(Kg) | 1.3 | 2 |
| A(mm) | 45 | 55 |
| B(mm) | 82.7 | 101.2 |
| C(mm) | 125.7 | 151.7 |
| ΦD(mm) | 40 | 55 |
| ΦE(mm) | 65 | 80 |
Features
